Feldis SSF chairlift and ski lifts.
About the SSF
Two cableways - one goal! Luftseilbahn Rhäzüns-Feldis AG LRF and Sesselbahn und Skilifte Feldis AG SSF are two economically independent companies that work closely together.
Chairlift
| Valley station | 1485 m above sea level. |
|---|---|
| Mountain station | 1974 m above sea level. |
| Height difference | 489 m |
| Track length | 1419 m |
| horizontal length | 1320 m |
| Medium gradient | 37% |
| Maximum gradient | 71% |
| Number of supports | 13 |
| Number of armchairs | 120 |
| Maximum driving speed | 2.3 m/s, corresponds to 8.3 km/h |
| Travel time | 10 min 28 s |
| Maximum conveying capacity per hour and direction | 700 persons |
| Main drive motor | Raschuns valley station |
|---|---|
| Motor ABB | Type M3BP 315SMC4 B3 |
| Performance | 147 kW |
| Speed | 1548 N |
| Suspension ropes | 9 mm diameter 8648 N max. rope force |
|---|
| Mechanical system components | GARAVENTA ropeways |
|---|---|
| Electrical control | Frey AG, Stans |
| Ropes | Fratzer AG, Romanshorn |
Borer ski lift
| Valley station | 1970 m above sea level. |
|---|---|
| Mountain station | 1996 m above sea level. |
| Height difference | 26 m |
| Track length | 152 m |
| horizontal length | 148 m |
| Medium gradient | 15% |
| Number of supports | 0 |
| Driving speed | 0.2 - 1.8 m/s, corresponds to 6.48 km/h |
| Travel time | 1 min 20 s |
| Passenger following time | 6.1 s |
| Conveying capacity per hour | 595 persons |
| Main drive motor | Valley station |
|---|---|
| Motor ABB | Type 1730 Valley / 730 Mountain |
| Performance | 7.5 kW |
| Speed | 2898 N |
| Suspension ropes | 38 mm diameter, 1045 kN breaking load |
|---|
| Mechanical system components | BORER Lift AG |
|---|---|
| Electrical control | BORER Lift AG |
| Ropes | 6x7 + FE Jakob |
